Body Assembly
No.
Name/Description
Part Code
200
Body Shell
D500 200
201
Chassis Moulding
D500 201
202
Windscreen (DOT & E marked)
D500 202
203
Rubber Surround Windscreen
D500 203
203a
Chrome Locking Strip Windscreen
D500 203a
204
Rear Window
D500 204
205
Rear Window Rubber
D500 205
205a
Rear Window Locking Strip
D500 205a
206
Door Window
D500 206
207
Door Window Rubber Surround
D500 207
207a
Door Window Locking Strip
D500 207a
208
O/S Sliding Window Front
D500 208
209
O/S Sliding Window Rear
D500 209
210
O/s Sliding Window Channel
D500 210
210a
O/s Sliding Window Flocked Channel
D502 210a
210b
O/s Sliding Window Rubber Surround
D502 210b
210c
O/S Sliding Window Chrome Locking Strip
D502 210c
211
Door Moulding
D502 211
212
Door Hinge Top
D502 212
213
Door Hinge Bottom
D502 213
213a
Door Hinge Nut + Washer (small)
D502 213a
213b
Door Hinge Nut + Washer (Large)
D502 213b
214
Offside Body Moulding
D501 214
214a
Offside Body Moulding Grille
D501 214a
215
Rear Body Moulding
D501 215
216
Body Moulding Clips
D501 216b
216a
Body Moulding Screw + Washers
D501 216a
231
Bumper
D500 231
231a
Bumper Rivet
D500 231a
404
Offside Mudguard Moulding
D502 404
405
Rear Mudguard Moulding
D502 405
407
Parcel Shelf Moulding
D502 407
